UL/cUL Certification 100Kva Single Phase Pad mounted Transformer 12KV DOE 2016 CSA ANSI IEEE Standards Residential Transformer

This 100 KVA pad-mounted transformer combines robust design with advanced functionality, tailored for efficient power distribution in urban and industrial settings. Featuring a 12000V Delta primary and 240/120V secondary voltage configuration, it seamlessly connects to 3-phase grids while delivering single-phase power, ideal for commercial and residential applications.​

The single-phase pad-mounted transformers manufactured by WINLEY not only fully comply with but also exceed ANSI, DOE, IEEE, and CSA standards. With UL/cUL certifications, these transformers stand out for their compact size, lightweight design, low noise operation, minimal power losses, as well as high safety and reliability. They are ideally suited for a wide range of applications, including residential communities, commercial centers, hospitals, parks, and schools.

Main data

Technical drawings

Built with copper windings, biodegradable natural vegetable oil ester insulating fluid , front-access 5-position tap changer, bayonet fused primary protection with isolation links, and a high-voltage elbow surge arrestor. Robust terminations, pressure-relief device, analog gauges, and a quiet 51 dBA sound level make it ideal for reliable, eco-friendly distribution use.

Specification

Production process

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.
